The FISSO articulated holder and mount is a highly adaptable accessory that is used to securely mount a machine vision camera or sensor in a fixed position to ensure accuracy and stability in imaging applications. The mount helps to eliminate movement or vibration that could affect image quality and distort the results. The FISSO machine vision mount can be adjusted to different angles, and some mounts can be customized to fit the camera or sensor's specific shape and size.
With just one central knob, it’s never been easier to position vision cameras, photoelectric sensors or lights for maximum visibility. Virtually any position, no matter how complex, can be created, easily adjusted and permanently fixed. This solution is much more time-saving than rigid and therefore non-adjustable camera mounts, and therefore more cost-effective.
Thanks to a wide range of basic components, your vision system is held precisely in place, above your conveyor line, aluminum frame system, or wherever you want it.
FISSO has various head components that fit the equipment of all major machine vision system manufacturers. Our design and manufacturing capabilities also allow us to provide custom OEM solutions.
OEM industrial holder
A customized FISSO holder can be constructed from our wide range of components.
Build a custom clamping system for holding heavyweight oder lightweight objects or components.
First choose a base, and then add the articulated arm, connectors, and clamps.
See Details.
Art.# OE20.10, OE20.20, OE20.30
For safely holding and positioning of machine vision Cameras and Monitors
Art.# OE26.10, OE26.20
For safely holding and positioning of machine vision Cameras and Monitors
Art.# OE44.10, OE44.20
For simple, fast and stable positioning of videoscopes, endoscopes or other objects with a Joystick handle
Art.# OE20.40, OE20.50
For safely holding and positioning of laser and light-guides
Art.# OE13.10, OE13.20
For safely holding and positioning of photoelectric sensors
Art.# OE20.80
For flexible and ergonomic positioning of smartphones / cellphones.
Art #. OE34.80
For flexible and ergonomic positioning of Tablets
Art.# 4.130
Articulating arm 200 mm M6-1/4″ 20 UNC
Art.# 85.030, 85.040
Compatible with T-Slot Aluminum frame 20×20, 30 x 30, 40 x 40 mm
Adapter compatible with many machine vision cameras
Art. # 1.250
For easy, flexible and fast mounting of optical sensors, vision cameras, lasers and lights
Art. # 5.610
Mounting clamp for mounting rod – bar. For diamerter D14-D12
Art. # 81.622, 81.670, 81.671
Material: Steel
# 81.622 D12 x 170 mm, M6 (Female)
# 81.670 D12 x 178 mm, M8 (Male)
# 81.671 D14 x 208 mm, M8 (Male)
Art #. 5.120, 5.130
it can quickly attach cameras, monitors, LED lights, etc. to round pipes, tables, handlebars, tripods and stabilizer handheld rings.
In addition, built-in cushions provide protection and clamping stability.
Art. #5.202, 5.204
For clamping round objects (sensors, lasers, tubes….) between 15 and 40 mm
Art.# 5.450, 5.451, 5.452
For securely holding devices or parts with a diameter between 9 and 16 mm
Art.# 5.060, 5.065, 5.079, 5.081, 5.082, 5.089
To be fixed in a magnetic material or surface
Art.# 5.090
The vacuum base adheres to all flat and non-porous surfaces.
Art.# 5.202, 5.204, 5.203, 5.208
For mounting on the edge of the table or similar
Art.# 5.031, 5.032, 5.040, 5.041
Stand-alone steel base in different sizes an weights available
Art.# 5.910, 5.911, 5.930, 5.931, 5.932, 5.933
Various adapters and connectors (See details)
Art. #5.440
Dimension D = 8mm, L = 200 mm, Male M6, Female M6 (Art. #5.440)
