Art. # 1.250
Swivel mount D14 D12
For easy, flexible and fast mounting of optical sensors, vision cameras, lasers and lights
Holders and Mounts for Machine Vision and Automation
The FISSO articulated holder and mount is a highly adaptable accessory that is used to securely mount a machine vision camera or sensor in a fixed position to ensure accuracy and stability in imaging applications. The mount helps to eliminate movement or vibration that could affect image quality and distort the results. The FISSO machine vision mount can be adjusted to different angles, and some mounts can be customized to fit the camera or sensor's specific shape and size.
With just one central knob, it’s never been easier to position vision cameras, photoelectric sensors or lights for maximum visibility. Virtually any position, no matter how complex, can be created, easily adjusted and permanently fixed. This solution is much more time-saving than rigid and therefore non-adjustable camera mounts, and therefore more cost-effective.
Thanks to a wide range of basic components, your vision system is held precisely in place, above your conveyor line, aluminum frame system, or wherever you want it.
FISSO has various head components that fit the equipment of all major machine vision system manufacturers. Our design and manufacturing capabilities also allow us to provide custom OEM solutions.
Art.# OE20.10, OE20.20, OE20.30
Machine Vision Camera-Monitor Mount 200 mm
For safely holding and positioning of machine vision Cameras and Monitors
Art.# OE26.10, OE26.20
Machine Vision Camera-Monitor Mount 260 mm
For safely holding and positioning of machine vision Cameras and Monitors
Art.# OE20.40, OE20.50
Laser-light guide holder 200 mm
For safely holding and positioning of laser and light-guides
Art.# OE13.10, OE13.20
Sensor Mount 130 mm
For safely holding and positioning of photoelectric sensors
Art.# 4.130
Articulated Arm 200 mm M6-1/4" 20 UNC
Articulating arm 200 mm M6-1/4″ 20 UNC
Art.# 4.030 – 4.160
Articulated arm Strato Line
https://fisso.com/en/field/industrial/articulated-arms-industry/
Art.# 85.030, 85.040
Mounting Plate
Compatible with T-Slot Aluminum frame 20×20, 30 x 30, 40 x 40 mm
Adapter compatible with many machine vision cameras
Art. # 5.610
Mounting Clamp for Rod D14-D12
Mounting clamp for mounting rod – bar. For diamerter D14-D12
Art. # 81.622, 81.670, 81.671
Mounting Rod, Mounting Bar in D12 and D14
Material: Steel
# 81.622 D12 x 170 mm, M6 (Female)
# 81.670 D12 x 178 mm, M8 (Male)
# 81.671 D14 x 208 mm, M8 (Male)
OEM industrial holder
Customized Holders for OEMs
A customized FISSO holder can be constructed from our wide range of components.
Build a custom clamping system for holding heavyweight oder lightweight objects or components.
First choose a base, and then add the articulated arm, connectors, and clamps.
See Details
4.070-VE
Articulated Arm for extreme temperatures
For use in temperatures between -55 and 150 °C (-67 and 310 F)
Very low magnetic property
Action radius: 200 mm
Art. #5.202, 5.204
Adjustable Sensor/Laser Clamp
For clamping round objects (sensors, lasers, tubes….) between 15 and 40 mm
Art.# 5.450, 5.451, 5.452
Laser Holder, Light guide holder - Tube holder
For securely holding devices or parts with a diameter between 9 and 16 mm
Art.# 5.060, 5.065, 5.079, 5.081, 5.082, 5.089
Magnetic Base
To be fixed in a magnetic material or surface
Art.# 5.090
Vacumm Base
The vacuum base adheres to all flat and non-porous surfaces.
Art.# 5.202, 5.204, 5.203, 5.208
Clamping Base
For mounting on the edge of the table or similar
Art.# 5.031, 5.032, 5.040, 5.041
Steel base
Stand-alone steel base in different sizes an weights available
Art.# 5.910, 5.911, 5.930, 5.931, 5.932, 5.933
Inox Thread adapters M6, M8, 1/4", 3/8" ww
Various adapters and connectors (See details)
Art.# 93.766, 93.767, 93.768
Adapter spigot - Connecting bolt
Various adapter spigot – Connecting bolt (see Details)
Art. #5.440
Extension
Dimension D=8mm, L=200 mm, Male M6, Female M6 (Art. #5.440)
